FPΣ User's Manual
7.4 Pulse Output Function
147
Pulse output diagram
Channel 2:

300ms 300ms
2000Hz
100Hz
0Hz
Channel 0:

300ms 300ms
2000Hz
100Hz
0Hz
1
Positioning start
2
Near home input
3
Home input
REFERENCE
For POU Header and POU Body, please see the programming examples in
Panasonic's download area.
Applicable FPWIN Pro Project:
• Sample_PulseOutput_04_HomeReturn_2Axes_LD_FPSIGMA.pro
• Sample_PulseOutput_04_HomeReturn_2Axes_ST_FPSIGMA.pro
