Version 7.11
28 | Programmable Outputs
Digiplex EVO • Programming Guide
065
(cont.)
Status 2
(cont.)
Refer to Notes for
Table 16 on page
21
Bypass, master, installer programming 006 006
Keypad lockout 007 007
066 Status 3
Refer to Notes for
Table 16 on page
21
Intellizone delay engaged** 000 000
Fire delay engaged 001 001
Auto arm 002 002
Arming with voice module (set until exit delay finishes) 003 003
Tamper 004 004
Zone low battery 005 005
Fire loop trouble 006 006
Zone supervision trouble 007 007
067** Special status -
Chime in partition 1 to 4
(000 to 003 = system 1 to 4)
000 to 003 000 to 003
Smoke detector power reset 004 004
Ground start 005 005
Kiss off 006 006
Telephone ring 007 007
Bell on partition 1 to 8
(008 to 015 = partitions 1 to 8)
008 to 015 008 to 015
Pulsed alarm in partition 1 to 8
(016 to 023 = partitions 1 to 8)
016 to 023 016 to 023
Open/close Kiss off in partition 1 to 8
(024 to 031 = partitions 1 to 8)
024 to 031 024 to 031
Keyswitch/PGM inputs # 01 to 32
(032 to 063 = Keyswitch/PGM inputs # 01 to 32)
032 to 063 032 to 063
Status of access door 01 to 32
(064 to 095 = access doors 01 to 32)
064 to 095 064 to 095
Trouble in system 096 096
Trouble in dialer 097 097
Trouble in module 098 098
Trouble in combus 099 099
Future use 100 to 102 100 to 102
Time and date trouble 103 103
AC failure 104 104
Battery failure 105 105
Auxiliary current limit 106 106
Bell current limit 107 107
Bell absent 108 108
ROM error 109 109
RAM error 110 110
Future use 111 111
TLM 1 trouble 112 112
Fail to communicate 1 113 113
Fail to communicate 2 114 114
Fail to communicate 3 115 115
Fail to communicate 4 116 116
Fail to communicate with PC 117 117
Future use 118 118
Future use 119 119
Module tamper trouble 120 120
Module ROM error 121 121
Module TLM error 122 122
Table 16: List of Event and Feature Groups (Continued)
A
Event Group
Event
B
Feature Group
Feature
C
Start #
D
End #
To Next Page
