Parker 10G-46-0600-BF

15-2 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F125
Jogging Acceleration Time
0.1～3000S
subject to
inverter
model
√
F126
Jogging Deceleration Time
0.1～3000S
√
F127
Skip Frequency A
0.00～590.0Hz
0.00
√
F128
Skip Width A
±2.50Hz
0.00
√
F129
Skip Frequency B
0.00～590.0Hz
0.00
√
F130
Skip Width B
±2.50Hz
0.00
√
F131
Running Display Items
0－Output frequency /
function code
1－Output RPM
2－Output current
4－Output voltage
8－DC Bus Voltage
16－PID feedback value
32－Temperature
64－Reserved
128－Linear speed
256－PID given value
512－Reserved
1024－Reserved
2048－Output power
4096－ Output torque
0+1＋2＋4＋
8＝15
√
F132
Display Items for Stop Mode
0: frequency / function code
1: Keypad jogging
2: Target RPM
4: DC Bus Voltage
8: PID feedback value
16: Temperature
32: Reserved
64: PID given value
128: Reserved
256: Reserved
512: Setting torque
2＋4＝6
√
F133
Drive Ratio of Driven System
0.10～200.0
1.0
√
F134
Transmission-wheel Radius
0.001～1.000
0.001
√
F135
Reserved
F136
Slip Compensation
0～10
0
╳
F137
Torque Compensation Mode
0: Linear compensation;
1: Quadratic compensation;
2: User-defined multipoint
compensation
3: Auto torque compensation
3
╳
