15-6 Parameter Reference
AC10 Inverter
Multifunctional Input and Output Terminals: F300-F330
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F300
Relay token output
0: No function
1: Inverter fault
2: At target frequency 1
3: At target frequency 2
4: Free stop (coast stop)
5: In running status 1
6: DC braking
7: Accel/decel time switchover
8-9: Reserved
10: Inverter overload pre-alarm
11: Motor overload pre-alarm
12: Stalling
13: Inverter is ready to run
14: In running status 2
15: At speed
16: Overheat pre-alarm
17: Over target output current
18: Analog input disconnection
19: Reserved
20: At Zero output current
21: DO1 controlled by PC/PLC
22: Reserved
23: TA, TC fault relay output
controlled by PC/PLC
24: Watchdog
25-39: Reserved
40: High-frequency performance
switchover
1
√
F301
DO1 token output
14
√
F302
DO2 token output
5
F303-
F306
Reserved
F307
Target frequency 1
F112～F111
10.00
√
F308
Target frequency 2
F112～F111
50.00
√
F309
Target frequency width (%)
0～100
50
√
F310
Target current (A)
0～1000
Rated
current
√
F311
Target current width (%)
0～100
10
√
F312
At speed threshold (Hz)
0.00～5.00
0.00
√
F313-
F315
Reserved
