Parker 10G-46-0600-BF

Parameter Reference 15-9
AC10 Inverter
Analog Input and Output: F400-F480
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F400
Lower limit of AI1 channel input
0.00～F402
0.01
√
F401
Corresponding setting for lower limit of AI1
input
0～F403
1.00
√
F402
Upper limit of AI1 channel input
F400～10.00
10.00
√
F403
Corresponding setting for upper limit of AI1
input
Max（1.00，F401）～2.00
2.00
√
F404
AI1 channel proportional gain K1
0.0～10.0
1.0
√
F405
AI1 filtering time constant
0.01～10.0
0.10
√
F406
Lower limit of AI2 channel input
0.00～F408
0.01V
√
F407
Corresponding setting for lower limit of AI2
input
0～F409
1.00
√
F408
Upper limit of AI2 channel input
F406～10.00
10.00V
√
F409
Corresponding setting for upper limit of AI2
input
Max（1.00，F407）～2.00
2.00
√
F410
AI2 channel proportional gain K2
0.0～10.0
1.0
√
F411
AI2 filtering time constant
0.01～10.0
0.10
√
F418
AI1 channel 0Hz voltage dead zone
0～0.50V (Positive-Negative)
0.00
√
F419
AI2 channel 0Hz voltage dead zone
0～0.50V (Positive-Negative)
0.00
√
F421
Panel selection
0: Local keypad panel
1: Remote control keypad panel
2: Local keypad + remote control
keypad
1
√
F422
Reserved
F423
AO1 output range
0：0～5V；
1：0～10V or 0-20mA
2: 4-20mA
1
√
F424
AO1 lowest corresponding frequency
0.0～F425
0.05Hz
√
F425
AO1 highest corresponding frequency
F424～F111
50.00Hz
√
F426
AO1 output compensation
0～120
100
√
F427
AO2 output compensation
0: 0～20mA
1: 4～20mA
0
√
F428
AO2 lowest corresponding frequency (Hz)
0.0～F429
0.05
√
F429
AO2 highest corresponding frequency (Hz)
F428～F111
50.00
√
F430
AO2 output compensation (%)
0～120
100
√
