Parker 10G-46-0600-BF

15-10 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F431
AO1 analog output signal selecting
0: Running frequency;
1: Output current;
2: Output voltage;
3: Analog AI1;
4: Analog AI2;
6: Output torque;
7: Given by PC/PLC;
8: Target frequency
0
√
F432
AO2 analog output signal selecting
1
√
F433
Corresponding current for full range of external
voltmeter
0.01～5.00 times of rated current
2
╳
F434
Corresponding current for full range of external
ammeter
2
╳
F435-
F436
Reserved
F437
Analog filter width
1～100
10
*
F438-
F459
Reserved
F460
AI1channel input mode
0: Straight line mode
1: Folding line mode
0
╳
F461
AI2 channel input mode
0: Straight line mode
1: Folding line mode
0
╳
F462
AI1 insertion point A1 voltage value
F400～F464
2.00V
╳
F463
AI1 insertion point A1 setting value
F401～F465
1.20
╳
F464
AI1 insertion point A2 voltage value
F462～F466
5.00V
╳
F465
AI1 insertion point A2 setting value
F463～F467
1.50
╳
F466
AI1 insertion point A3 voltage value
F464～F402
8.00V
╳
F467
AI1 insertion point A3 setting value
F465～F403
1.80
╳
F468
AI2 insertion point B1 voltage value
F406～F470
2.00V
╳
F469
AI2 insertion point B1 setting value
F407～F471
1.20
╳
F470
AI2 insertion point B2 voltage value
F468～F472
5.00V
╳
F471
AI2 insertion point B2 setting value
F469～F473
1.50
╳
F472
AI2 insertion point B3 voltage value
F470～F412
8.00V
╳
F473
AI2 insertion point B3 setting value
F471～F413
1.80
╳
