Multi-stage Speed Control: F500-F580
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F500
Stage speed type
0: 3-stage speed;
1: 15-stage speed;
2: Max 8-stage speed auto circulating
1
╳
F501
Selection of Stage Speed Under Auto-
circulation Speed Control
2～8
7
√
F502
Selection of Times of Auto- Circulation
Speed Control
0～9999（when the value is set to 0, the
inverter will carry out infinite circulating）
0
√
F503
Status after auto circulation running
Finished
0: Stop
1: Keep running at last stage speed
0
√
F504
Frequency setting for stage 1 speed
F112～F111
5.00Hz
√
F505
Frequency setting for stage 2 speed
F112～F111
10.00Hz
√
F506
Frequency setting for stage 3 speed
F112～F111
15.00Hz
√
F507
Frequency setting for stage 4 speed
F112～F111
20.00Hz
√
F508
Frequency setting for stage 5 speed
F112～F111
25.00Hz
√
F509
Frequency setting for stage 6 speed
F112～F111
30.00Hz
√
F510
Frequency setting for stage 7 speed
F112～F111
35.00Hz
√
F511
Frequency setting for stage 8 speed
F112～F111
40.00Hz
√
F512
Frequency setting for stage 9 speed
F112～F111
5.00Hz
√
F513
Frequency setting for stage 10 speed
F112～F111
10.00Hz
√
F514
Frequency setting for stage 11 speed
F112～F111
15.00Hz
√
F515
Frequency setting for stage 12 speed
F112～F111
20.00Hz
√
F516
Frequency setting for stage 13 speed
F112～F111
25.00Hz
√
F517
Frequency setting for stage 14 speed
F112～F111
30.00Hz
√
F518
Frequency setting for stage 15 speed
F112～F111
35.00Hz
√
F519-
F533
Acceleration time setting for the speeds from
Stage 1 to stage 15
0.1～3000S
Subject to
inverter
model
√
F534-
F548
Deceleration time setting for the speeds from
Stage 1 to stage 15
0.1～3000S
√
F549-
F556
Running directions of stage speeds from
Stage 1 to stage 8
0: Forward running;
1: Reverse running
0
√
F557-
F564
Running time of stage speeds from Stage
1 to stage 8
0.1～3000S
1.0S
√
F565-
F572
Stop time after finishing stages from Stage
1 to stage 8.
0.0～3000S
0.0S
√
F573-
F579
Running directions of stage speeds from
Stage 9 to stage 15.
0: Forward running;
1: Reverse running
0
√
F580
Reserved
