Parker 10G-46-0600-BF

15-12 Parameter Reference
AC10 Inverter
Auxiliary Functions: F600-F670
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F600
DC Braking Function Selection
0: Disabled
1: Braking before starting
2: Braking during stopping
3: Braking during starting and stopping
0
×
F601
Initial Frequency for DC Braking
0.20～50.00
1.00
√
F602
DC Braking level before Starting (V/A)
0～100
10
√
F603
DC Braking level During Stop (V/A)
0～100
10
√
F604
Braking Lasting Time Before Starting
0.00～30.00
0.50
√
F605
Braking Lasting Time During Stopping
0.00～30.00
0.50
√
F606
Reserved
F607
Stall Adjustment Function
0: Disabled
1: Enabled
2: Reserved
3: Voltage current control
4: Voltage control
5: Current control
0
√
F608
Stall Current Level (%)
60～200
160
√
F609
Stall Voltage Level (％)
110～200
1 phase: 130
3 phase: 140
√
F610
Stall Time Protection
0.1～3000
60.0
√
F611
Dynamic Braking Threshold (V)
200~1000
Subject to
inverter
model
△
F612
Dynamic Braking Duty Ratio (%)
0～100％
80
╳
F613
Flycatching
0: Invalid
1: Valid
2: Valid at the first time
0
╳
F614
Flycatching Rate Mode
0: Flycatching from frequency
memory
1: Flycatching from max frequency
2: Flycatching from frequency
memory and direction memory
3: Flycatching from max frequency
and direction memory
0
╳
F615
Flycatching Rate
1～100
20
╳
F616-
F618
Reserved
F619
Flycatching (fault) Time out (S)
0~3000
60
F620 –
F621
Reserved
F622
Dynamic Braking Mode
0: Fixed duty ratio
1: Auto duty ratio
0
√
