Parker 10G-46-0600-BF

15-14 Parameter Reference
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F706
Inverter Overloading coefficient％
120～190
150
╳
F707
Motor Overloading coefficient ％
20～100
100
╳
F708
Trip 1 Type (Newest)
Setting range:
2: Over current (OC)
3: Over voltage (OE)
4: Input phase loss (PF1)
5: Inverter overload (OL1)
6: Under voltage (LU)
7: Overheat (OH)
8: Motor overload (OL2)
11: External malfunction (ESP)
12: Current fault before running (Err3)
13. Studying parameters without
motor (Err2)
15: Current sampling fault (Err4)
16: Over current 1 (OC1)
17: Output phase loss (PF0)
18: Aerr analog disconnected
23: Err5 PID parameters are set wrong
45: Communication Timeout (CE)
46: Flycatching fault (FL)
49: Watchdog fault (Err6)
67: Overcurrent (OC2)
△
F709
Trip 2 Type
△
F710
Trip 3 Type
△
F711
Trip 1 Fault Frequency
△
F712
Trip 1 Fault Current
△
F713
Trip 1 Fault DC Bus Voltage
△
F714
Trip 2 Fault Frequency
△
F715
Trip 2 Fault Current
△
F716
Trip 2 Fault DC Bus Voltage
△
F717
Trip 3 Fault Frequency
△
F718
Trip 3 Fault Current
△
F719
Trip 3 Fault DC Bus Voltage
△
F720
Number of Overcurrent Faults
△
F721
Number of Overvoltage Protection Faults
△
F722
Number of Overload Protection Fault
△
F723
Number of Overload Protection Fault
△
F724
Input Phase Loss
0: Disabled
1: Enabled
1
○╳
F725
Reserved
F726
Overheat
0: Disabled
1: Enabled
1
○╳
F727
Output Phase Loss
0: Disabled
1: Enabled
0
○
F728
Input Phase Loss Filtering Constant
0.1～60.0
0.5
√
F730
Overheat Protection Filtering Constant
0.1～60.0
5.0
√
