9-6 Function Parameters
AC10 Inverter
Whatever the value of F131 is set to, corresponding target frequency will flash under stopped
status.
Target rotary speed is an integral number. If it exceeds 9999, add a decimal point to it.
If it exceeds 999, add a decimal point to it.
If it exceeds 9999, add two decimal points to it, and the like.
F132 Display items of stop
0: Frequency/function-code
1: Keypad jogging
2: Target rotary speed
4: DC Bus Voltage
8: PID feedback value
16: Temperature
32: Reserved
64: PID given value
128: Reserved
256: Reserved
512: Setting torque
F133 Drive ratio of driven system
Setting range: 0.10~200.0
F134 Transmission-wheel radius
Calculation of rotary speed and linear speed:
For example, If inverter’s max frequency F111=50.00Hz, numbers of motor poles F804=4,
drive ratio F133=1.00, transmission-shaft radius R=0.05m, then
Transmission shaft perimeter: 2πR =2×3.14×0.05=0.314 (meter)
Transmission shaft rotary speed: 60× operation frequency/ (numbers of poles pairs × drive
ratio) =60×50/ (2×1.00) =1500rpm
Maximum linear speed: rotary speed × perimeter=1500×0.314=471(meters/second)
Under V/HZ controlling, rotary speed of motor rotor will decrease as load increases. Be
assured that rotor rotate speed is near to synchronization rotary speed while motor with rated
load, slip compensation should be adopted according to the setting value of frequency
compensation.
Note: During the process of Flycatching, slip compensation function is invalid. After
Flycatching is finished, this function is valid.
F137 Modes of torque
compensation
0: Linear compensation;
1: Square compensation;
2: User-defined multipoint compensation
3: Auto torque compensation
Mfr’s value:
subject to
inverter model
1: 1.5
2: 1.8
3: 1.9
4: 2.0
