9-44 Function Parameters
AC10 Inverter
FA02 PID feedback signal given source
Setting range:
1: AI1
2: AI2
Mfr’s value: 1
When FA02=1, PID reference feedback signal is given by external analog AI1.
When FA02=2, PID reference feedback signal is given by external analog AI2.
FA03 Max limit of PID adjusting (%)
FA04～100.0
Mfr’s value：100.0
FA04 Digital setting value of PID adjusting (%)
FA05～FA03
Mfr’s value：50.0
FA05 Min limit of PID adjusting (%)
0.1～FA04
Mfr’s value：0.0
When FA01=0, the value set by FA04 is digital setting reference value of PID adjusting.
FA06 PID polarity
0: Positive feedback
1: Negative feedback
Mfr’s value：1
When FA06=0, the higher feedback value is, the higher the motor speed is. This is positive
feedback.
When FA06=1, the lower the feedback value is, the higher the motor speed is. This is negative
feedback.
The inverter will restart if the feedback value drops below the value of FA05, PID minimum
limit. Therefore, the value of FA05 should be increased from the default value of 0.0 when
using the PID sleep function. This is true when FA06 is set to 1. When FA06 is 0 you should
set FA03 lower than 100 as the feedback value has to exceed this limit.
FA07 Sleep function selection
Setting range:
0: Enabled
1: Disabled
Mfr’s value: 1
When FA07=0, if inverter runs at the min frequency FA09 for a period time set by FA10,
inverter will stop.
When FA07=1, the sleep function is disabled.
FA09 Min frequency of PID adjusting (Hz)
Setting range:
F112~F111
Mfr’s value: 5.00
The min frequency is set by FA09 when PID adjusting is valid.
FA10 Sleep delay time (s)
Setting range:
0~500.0
Mfr’s value: 15.0
FA11 Wake delay time (s)
Setting range:
0.0~3000
Mfr’s value: 3.0
FA12 Maximum output frequency of PID loop
Setting range:
FA09 – F111
Mfr’s value:
50.00
FA18 Whether PID adjusting target is changed
0: Invalid
1: Valid
Mfr’s value: 1
When FA18=0, PID adjusting target cannot be changed.
