Pco Edge 3.1 User Manual

38
Convert Control Color (only pco.edge color)
Color Balance (Histogram of original data)
Intensity of single color can be controlled by
Saturation and Vibrance
.
Press the Auto button to set the white
balance
.
The balancing of RGB can be controlled by
Col.Temp and Tint
.
It is possible to
hide the histogram of original
data and to switch tab/histogram .
The user can influence how the 16 bit intensity values of the original
image are displayed in 8 bit values in different ways.
White sliders in histogram
left slider = Min controller (corresponds to value 0 of the 8 bit
display). Values below that mark are set to 0, i.e. displayed as no
color.
right slider = Max controller (corresponds to value 255). Values
above that mark are set to 255, i.e. displayed as full color.
The values in-between are converted into a value between 0 and 255
according to Contrast and Gamma settings. See the small graph ,
which reflects the calculation.
Proc. Config (Process configuration)
Due to proprietary high-end algorithms used for these image
processing features, no detailed description is given here
Converted RGB Hist
This tab shows you the histogram of
converted data.
GPU Processing
On: Switch on in order to significantly reduce
processing time (increases refresh rate of the
live image.
Fast pco debayering: only color cameras
Color Refine Filter only color cameras
Noise Reduction
NLM: Non local means algorithm
Denoise Adaptive: only color cameras
Sharpen:
On: only color cameras (first activate Fast
pco debayering
1
2
3
4
5
6
7
1
2
3
4
5
6
7
3
4
1
3
4
2
1
2
