A4 INTERFACES

Three different interfaces are available for the pco.edge camera. This

chapter describes the installation and configuration of USB 3.0,

Camera Link and Camera Link HS interfaces.

Furthermore USB range extension, Ring Buffer and FIFO Buffer are

described in detail.

A4.1 CABLE POSSIBILITIES

Overview of the maximum cable lengths.

Camera Link HS

• FOL fiber optic cable LC multi mode function

• standard: 10 m (multi mode)

• maximum: 300m (multi mode)

Camera Link full (2 cables):

• standard: 3 m

• optional: 5 m

• maximum: 7 m (active cable)

USB 3.0:

• standard: 3 m

• cable and proper PCI express board included in the camera

system

NOTE

Please only use Camera Link cables, which are approved by PCO.

Otherwise full functionality is not guaranteed.

NOTE

Please only use USB 3.0 cables, which are approved by PCO.

Otherwise full functionality is not guaranteed.
