48
6.9 CAMWARE MENU TABS & FEATURES
This chapter describes in detail the Camware Demo Mode and the
Camware Tabs: File, Camera, Acquisition, View and Window.
Furthermore the right-click menu and some additional features are
listed.
6.9.1 DEMO MODE
When Camware is started, it automatically recognizes the
camera type of the connected and running cameras.
Camware will start in Demo Mode, if your camera is switched
off or no camera is connected
In this mode all image processing features are available, but
all camera settings are deactivated. The user only has to tell
Camware what type of image he wants to open. For that
purpose, the Demo Mode Setup window opens and asks for
the corresponding input.
Need Help? If this window pops up because you have trouble
running the camera, please see instructions in appendix A8.
Resolution
The drop down list displays the existing image sensor spatial
resolutions of all PCO camera systems. Please select the specific
resolution and bit depth of the images to be opened. If double shutter
images have been recorded and should be opened, Double Shutter
Mode should be checked.
Color
With the radio buttons, the user can specify whether the image type
is monochrome (b/w) or color.
Alignment
These two radio buttons adjust whether MSB (most significant bit)
aligned (upper) or LSB (least significant bit) aligned (lower) images
have been stored.
Infotext
The Infotext is automatically shown in Camware if
you open a stored image sequence.
The Camera Properties settings, storing location
and Record date are listed in this file.
Infotext can be activated in the View Menu 6.9.5 at
any time.
