57
Flip/Mirror: image will be flipped or mirrored.
Rotate Left/Right: rotates the image.
Set ‘File Save ROI’: if you want to save just a
part of the recorded image (region of interest),
it is possible to draw a rectangle with the
mouse. This rectangle is valid for all recorded
images and can be dragged at its edges.
Line Tool: select Line Tool to show a graph,
which shows the intensity of the pixels under
the red line shown in the image window. The
selection of this menu item determines the
location of the first point. After this you can
move the mouse to the second point, which
can be selected by a left click. Now a Line
Diagram opens and the length of the line (unit:
pixel) is displayed in the window.
It is possible to lengthen, shorten or move this
line
Crosshair: activates a centered crosshair. Size
and color are selectable see chapter Fehler!
Verweisquelle konnte nicht gefunden werden.
→ Options.
Crosshair is movable, just drag it by mouse.
Reset it to center position by double-click into
center of the crosshair.
Copy to Clipboard: will copy the actual image to clipboard.
Properties: shows the current settings for View Mode / Common
View Mode and Image Conversion.
