Pco Edge 3.1 User Manual

80
USB 3.0 extension card with xHCI4 host controller
The following companies manufacture USB 3.0 xHCI host controller:
• Renesas Electronics America Inc. (earlier NEC),
• Texas Instrument Inc.,
• VIA Labs Inc (Diamond),
• Fresco Logic Inc.,
• Intel Inc.,
• AMD Inc. and
• Etron Technology, Inc.
To determine suitable manufacturers of the xHCI controller, please
use the Windows Device Manager. For example, in Windows 7 drop
down the USB Controller entry and find the USB 3.0 host xHCI
controller of the USB 3.0 device in the sub-tree. Then right-click to
open the properties dialog, click the details tab, and choose Vendor
in the properties pull-down box.
USB 3.0 interface cards with controllers from Etron Technology, Inc.
have not yet been tested.
The following table gives an overview about tested and
recommended system configurations or hardware components.
Component Recommendation
Motherboard
There is no recommendation for a manufacturer. But
if an onboard USB 3.0 port is used, the Renesas´s
xHCI host controller
μ
PD720202 is recommended.
USB 3.0
extension card
• DELOCK 89348 (U3-PCIE1XG202-10)
PCIe x1 V2.0 (μPD720202 host controller),
• DELOCK 89325 (U3X4-PCIE4XE101)
PCIe x4 V2.0 (
μ
PD720202 host controller)
PCIe Slot A PCIe 4x, 8x or 16x slot is recommended.
USB 3.0 Cable
USB 3.0 cable included in the packaging of your pco
USB 3.0 camera
USB 3.0 Hub Not recommended
Operating System Win 7 / 8 / 10 32bit & 64bit
Multiple pco USB
3.0 cameras
connected to a
PC
A separate DELOCK 89348 (U3-PCIE1XG202-10)
extension card for each camera should be used to
guaranty maximum data throughput of each camera.
Recommended Software Components
The pco USB 3.0 driver supports Windows 7/8 (x86 or x64) and
Windows XP x86 operating systems. Microsoft does not support USB
3.0 natively for Win 7 or older Windows versions. Therefore use the
manufacturers’ supplied xHCI host controller driver. By contrast, in
Windows 8 Microsoft does provide a native generic xHCI Driver but
pco recommends using the driver from the corresponding
manufacturer of the xHCI host controller. Currently there are seven
different vendors producing USB 3.0 host controllers:
NOTICE
NOTICE
