Pentax 645D User Manual

22
Before Using Your Camera
1
Memo
• Press the I button to illuminate the LCD panel.
LCD Panel
1 Multi-exposure
2 Beep
Appears when Beep is on.
(z p.R24)
3 HDR Capture (z p.R16)
4 Mirror Up
5 White Balance (p.50)
6 Shutter speed
7 Aperture value
8 Drive Mode (p.53)
9: Single Frame Shooting
j: Continuous Shooting
g: Self-timer shooting
W: Remote Control
shooting
9 EV bar/Electronic Level
Display/EV Compensation
(p.48)
10 Battery level (p.29)
11 Flash Exposure
Compensation (p.59)
12 SD2 Image File Format/JPEG
Recorded Pixels/JPEG Quality
(p.42)
1: RAW capture
1P: RAW+JPEG capture
13 SD1 Image File Format/JPEG
Recorded Pixels/JPEG Quality
(p.42)
14 e-dials
Appears when the adjustment
is available.
15 ISO/ISO AUTO
Appears when the sensitivity is
displayed.
16 Sensitivity/EV compensation
value
17 Copyright Information
embedded (z p.R27)
18 Interval Shooting (p.54)
19 Auto Bracketing
Blinks when used together
with Extended Bracketing.
INT.
7
6
5
9
8
13
2017 18 19
161514
10
11
12
12 3 4
20 Remaining image storage
capacity/USB connection
mode (z p.R25)/Sensor
Cleaning (z p.R29)
Pc-S: MSC mode
Pc-P: PTP mode
Cln: During sensor cleaning
e_kb487.book Page 22 Wednesday, December 8, 2010 9:49 AM

Pentax 645D Specifications

General

Sensor Type	CCD
Sensor Size	44 x 33 mm
Effective Pixels	40 megapixels
Autofocus Points	11
Image Processor	PRIME II
Continuous Shooting Speed	1.1 fps
Screen Size	3.0 inches
Screen Resolution	921, 000 dots
Viewfinder Type	Pentaprism
Viewfinder Coverage	98%
Storage Media	Dual SD/SDHC card slots
Dimensions	156 x 117 x 119 mm
Camera Type	Digital SLR
Shutter Speed	1/4000 to 30 sec
Battery Type	Rechargeable Lithium-Ion Battery
Weight	1480 g
