Perle IOLAN STS - Rj45; DB9 Male

Pinouts and Cabling Diagrams 357
EIA-232 Cabling Diagrams
RJ45
This cabling table does not apply to the SCS48C model.
DB9 Male
IOLAN RJ45
Terminal DB25
(DTE)
10-pin 8-pin
4 (DSR) 3 20 (DTR)
3 (RTS) 2 5 (CTS)
5 (TxD) 4 3 (RxD)
6 (RxD) 5 2 (TxD)
7 (GND) 6 7 (GND)
8 (CTS) 7 4 (RTS)
9 (DTR) 8 6 (DSR)
IOLAN DS1
DB9 Male
Terminal DB25
(DTE)
3 (TxD) 3 (RxD)
2 (RxD) 2 (TxD)
7 (RTS) 5 (CTS)
8 (CTS) 4 (RTS)
6 (DSR) 20 (DTR)
5 (GND) 7 (GND)
4 (DTR) 6 (DSR)
