Pinouts and Cabling Diagrams 359

EIA-232 Cabling Diagrams

DB9 Male

IOLAN DS1

DB9 Male

Modem DB25

(DCE)

1 (DCD) 8 (DCD)

2 (RxD) 3 (TxD)

3 (TxD) 2 (RxD)

4 (DTR) 20 (DTR)

5 (GND) 7 (GND)

6 (DSR) 6 (DSR)

7 (RTS) 4 (CTS)

8 (CTS) 5 (RTS)
