Getting to Know Your IOLAN
36 IOLAN SDS/SCS/STS User’s Guide, Version 3.6
I/O
This sections describes the basic components found on the IOLAN I/O models.
Top View
The following image shows a typical IOLAN I/O model. Your I/O model may have I/O connectors in
slightly different positions.
End View
The IOLAN I/O model shown is an A4D2. Different IOLAN I/O models have different I/O connector
configurations.
All IOLAN I/O models have a DB9M serial connector.
Serial Activity
Activity (LAN)
Link/10/100
Power/Ready
External Power Supply
Serial Port
Ethernet
Reset
Console/Serial
Switch
External Power Supply
I/O connectors
I/O connectors
