User Guide – PERC2000 System Controller
Publication 81-9059-0605-0, Rev. B
November 2010
Proprietary Information of
PESA 6-2
TWO JUMPER SHUNTS
(PESA PART NUMBER 81902912570)
MUST BE INSTALLED AS SHOWN
ALL SWITCHES MUST BE SET
TO THE “OFF” POSITION
(DIRECTION OF ARROW)
Pin 1
Pin 6
Figure 6-1 PERC2000 Jumper and Switch Locations
