8.9.14 S
ALVO
I
NCLUDE
L
ISTS
C
ONFIGURATION
S
CREEN
The Salvo Include Lists Configuration Screen, Figure 8-52, allows you to selectively build a
named list of salvo groups which, when assigned to a specific remote control panel, designates
the salvo groups that panel is authorized to control. Multiple panels may share a Salvo Include
List. Clicking on the Salvo Include Lists parent entry in the Command Screen Window brings
up a clean copy of the working screen. Note that the screen has three areas:
Figure 8-52 Salvo Include Lists Configuration Screen
Salvo List Name – This field is where you assign a name to the Salvo Include List. Names can
be any combination of letters and numbers up to eight characters. PESA highly recommends
that you choose a name which is somewhat descriptive of the function of the salvo include list.
Salvo List names may be from one to eight characters in length and are constructed using
uppercase letters, numbers, and spaces. The first character must be a letter.
Salvo List – Salvo groups listed in this column are accessible by remote control panels
functioning under the named salvo include list.
Available Salvo Groups – This column contains a listing of all salvo groups which may be
included in the salvo include list.
Initially, all salvo groups are listed in the Available Salvo Groups list box. Listed salvo groups
are moved between the two list boxes using the two arrows between the boxes. In order to
move a salvo group name from the available list to the salvo include list, highlight the salvo
group you want to include in the list and click the arrow pointing from the available list to the
include list. In order to disallow a salvo group from the include list, highlight and move the
salvo group name from the include list to the available list using the arrow pointing to the
available list.
