6.4.3 P OWER S UPPLY M ODULE R EMOVAL AND I NSTALLATION
Remove either power supply module as follows:
1. Disconnect the power cord of the power module you wish to remove from its source of
primary power.
2. On the rear panel of the chassis frame, remove the power cord from the module.
2. Using the small handle on the front, pull the power module toward you to unseat it from
its mating connector.
2. Carefully slide the module assembly out of the chassis
Install either power supply module as follows:
1. Align the module assembly with the guides in the chassis slot.
2. Carefully, slide the module into the chassis until the rear connector makes contact with
the connector on the backplane.
3. Firmly, push the module into the chassis until the connectors are fully mated.
4. Install the power cord plug onto the mating module power pins accessible through the
rear panel cutout.
5. Connect the power cord to a source of primary power.
