8.9.3.5 Component Type
Component Type is a pull-down menu list containing acronyms defining the types of hardware
devices controlled by the P2K controller from the following options:
PRC – Describes any PESA switching product using the PESA Routing Control (PRC) bus for
control interface.
TGR – Describes the legacy PESA Tiger Series of switching products.
XTN – Describes an External Control Bus to interface with non-PESA equipment.
P2 – Reserved for future use.
DRS – Describes the Cheetah DRS Series of audio routing products.
Highlight and select the proper hardware designator corresponding to the type of hardware
routing the component.
8.9.3.6 Strobe
Strobe defines a numeric digit identifying the physical hardware routing the component.
8.9.3.7 Description
Description is a free text field where you can enter a full description of the switching
component or add notes or information as desired. This field is solely for discretionary use and
has no effect on the defined component characteristics.
8.9.3.8 Adding or Deleting Components
Adding a Component - P2K allows a maximum of 64 components. To add a component,
simply click on the Components parent header to access a blank Components Configuration
Screen. You may also right click the mouse with the cursor over the Components parent
header, or any sub-header, select the “Add Component” option from the click box, Figure 8-23,
and a blank Components Configuration Screen is displayed.
Deleting a Component - To delete a component, expand the Components parent header to
display the list of assigned components. Click on the name of the component you wish to
delete, right click the mouse and select the “Delete Component” option from the click box,
Figure 8-23.
