Phoenix LT4 User Manual

Phoenix LT4 Lane Machine Operation, Maintenance, and Parts Manual
61-900040-000 Rev. Date 01/22
7-27
Oiling & Buffing System
NUMBER
DESCRIPTION
NUMBER
DESCRIPTION
1
01-024
SCREW, PAN HEAD, 10-32 X 1
11
294-116-090
LEFT HAND BUFFER MOUNTING ASM
2
294-116-025
BUFFER MOTOR NUT PLATE
12
294-116-093
RIGHT HAND BUFFER MOUNTING ASM
3
294-116-054
OIL TANK SPRING
13
294-116-095
294-116-094
LEFT HAND BUFFER SOLENOID ASM, 110V
LEFT HAND BUFFER SOLENOID ASM, 220V
4
294-116-055
BUFFER RETURN SPRING
14
294-116-097
294-116-096
RIGHT HAND BUFFER SOLENOID ASM, 110V
RIGHT HAND BUFFER SOLENOID ASM, 220V
5
294-116-062
TRANSFER ROLLER DRIVE ASM
15
294-116-099
TRANSFER CHAIN
6
294-116-065
BUFFER BRUSH
16
294-116-150
TRANSFER MOTOR ASM
7
294-116-068
OIL TANK ASM
17
801-749-081
SCREW, FLANGE HEAD HEX, 1/4-20 X 1/2
8
294-116-071
294-116-070
BUFFER MOTOR ASM, 110V
BUFFER MOTOR ASM, 220V
18
801-749-121
SCREW, FLANGE HEAD HEX, 1/4-20 X 3/4
9
294-116-082
BUFFER BELT
19
843-140-002
NUT, KEPS, 10-32
10
294-116-083
TRANSFER MOTOR SHIM
20
856-149-001
NUT, HEX FLANGE STOVER LOCK, 1/4-20
