Physio Control lucas 2 - Spare Parts and Accessories; Service Spare Parts List

LUCAS® 2 Chest Compression System – Service Manual
3323809-001, © 2017 Physio-Control, Inc.
33
6. Spare Parts and Accessory List
6.1. Service Spare Parts List
Catalog
#
Product description
Drawing#
Note
21576-000006 LUCAS 2 COMPRESSION MODULE 150401-00
Including motor
21576-000066
LUCAS 2.2 COMPRESSION MODULE
150401-20
Including motor
21576-000016
LUCAS 2 REFURBISHING KIT 150402-00
Carrying case,
patient straps
and
stabilization strap
21576-000008
LUCAS 2 HOOD W ITH USER PANEL
150403-00
21576-000067
LUCAS 2.2 HOOD W ITH USER
150403-20
21576-000009 LUCAS 2 BELLOW S
150404-00
Including
brackets
21576-000010
LUCAS 2 ELECTRIC FAN
150405-00
21576-000011 LUCAS 2 ELECTRIC MOTOR 150406-00
Including drive belt
21576-000068 LUCAS 2 ELECTRIC MOTOR 2.2 150406-20
Including drive belt
21576-000012
LUCAS 2 SHAFT SEAL
150407-00
21576-000013 LUCAS 2 SUPPORT LEG 150408-00
Including angle shafts,
strap holders, snap rings,
and torsion
-spring
21576-000014
LUCAS 2 CONTROL BOARD
150409-00
Including bracket
21576-000069
LUCAS 2 CONTROL BOARD 2.2
150409-20
Including bracket
21576-000015
LUCAS 2 PROTECTIVE BOARD
150410-00
Including bracket
21576-000071
LUCAS 2 PROTECTIVE BOARD 2.2
150410-20
Including bracket
21576-000007
LUCAS 2 DRIVE BELT
150411-00
21576-000019
LUCAS 2 INTERNAL
COMMUNICATION CABLE
150413-00
15
-pin cable between
control board and
protective board
21576-000070
LUCAS 2 INTERNAL
COMMUNICATION CABLE 2.2
150413-20
15
-pin cable between
control board and
protective board
21576-000020
LUCAS 2 HOOD
COMMUNICATION CABLE
150414-00
Flat cable between
hood and protective
board
21576-000025
LUCAS 2 BATTERY
CONNECTOR BOARD
150415-00
Including O
-rings
21576-000026 LUCAS 2 FRAME ASSY 150416-00
Main body with support
legs mounted
21576-000027 LUCAS 2 POW ER INLET 150417-00
DC
-
inlet connector (main
body) including cable
21576-000072 LUCAS 2 POW ER INLET 2.2 150417-20
DC-inlet connector
(main body)
including cable
Figure 6.1-1: Table – Service Spare Parts List
