Physio Control lucas 2 - Other Orderable Spare Parts

LUCAS® 2 Chest Compression System – Service Manual
3323809-001, © 2017 Physio-Control, Inc.
34
6.2. Other Orderable Spare Parts
Catalog#
Product description
Drawing#
Note
21576-000073
MAIN BODY COMPLETE
100652-00
21576-000047
SCREW PT K40X12 W N
1452 A2
10150120-43
QTY: 4, Used to attach Hood to
main body
21576-000049
WASHER 3X10X3.4
ARAN LOCK
10150085-29
QTY: 4, Used to attach
Thread
Plate to main body
21576-000050 AXEL-ANGLE SHAFT
240-3
QTY: 4, Used to attach Support Leg
to Main Body
21576-000051
TORSION SPRING
240-9
21576-000053
SCREW K40X14 W N1452
10150120-35
QTY: 6, For one Support Leg
21576-000054
SCREW DELTA PT
40X22 WN5452
10150461-00
QTY: 3, For one Support Leg
Assembly
Used to attach two pieces of
Support Leg. These three screws
are in the middle of the Support
Leg.
21576-000055
BELT COVER
100654-00
21576-000056
SCREW MRT M3X6 A2
ISO 7045
1015007161
QTY: 4, Used to attach Control and
Protective Board Assembly to the
Compression Module Assembly
21576-000057
SERRATED LOCK W
ASHER M3 DIN
698A
1015021803
QTY: 4, Used to attach Belt Cover
to Compression Module Ass
embly
21576-000058
SCREW MRT M4x12 A2
ISO 7045
1015007178
QTY: 4, Used to attach Motor with
Belt Wheel Assembly to
Compression Module Assembly
21576-000059
SERRATED LOCK W
ASHER M4 DIN
6798A
1015021804
QTY: 1, Used between one screw
and the Terminal
21576-000060
TERMINAL M4 AMP
181949
1067227820
QTY: 1, Used to attach Ground
Cable from Hood Assembly
21576-000061
SCREW MFX-H M3x6 A2
DIN 965
724322040
QTY: 4, Used to attach Mesh and
Threaded Plate on air intake side.
21576-000062
SCREW MFS M3x40 A2
DIN 963
723123842
QTY: 4, Used to attach Mesh, Fan
Washer, Fan cable assembly and
Threaded Plate.
21576-000063
SCREW MRX-H M3x50
A2 DIN 98
724124040
QTY: 4, Used to attach Hood
21576-000064 SCREW MFT M5x20 A2
1015007248
QTY: 8, Used to attach
Compression Module Assembly and
Protective and Control board
assembly to Upper Part Assembly
21576-000065
SCREW MRT M3x12 A2
ISO 7045
1015007163
QTY: 2, Used for tightening the
clamp on Bellows
21501-002658
TYPE LABEL
100630-00
2.0/2.1 serial
21501-002854
TYPE LABEL LUCAS
22
100905-00
2.2 serial
21501-002855 LABEL, UDI
100952-00
QTY: 1, LUCAS 2 UDI Label,
placed on the opposite leg
compared to the Type Label
21576-000089
BRACKET, HOOD,
LUCAS
100909-00
QTY: 1, metal bracket for fixation
HOOD
21576-000090 CARD, MEMORY, SD
300027-00
QTY: 1, LUCAS SD Card for storing
Log files, positioned on the Control
Board
Figure 6.2-1: Table – Other Orderable Spare Parts List
