LUCAS® 2 Chest Compression System – Service Manual
3323809-001, © 2017 Physio-Control, Inc.
40
Apply the grease onto the Carry Ball Screw with the syringe (0.5 ml).
Figure 8.2-3: Lubrication of the Carry Ball Screw
Move the piston manually up and down 5 times over the full range to work the grease in.
8.4. Claw Lock Lubrication
Use PTFE Spray Lubricant (21576-000023)
Spray a small quantity of lubricant on all movable parts (gliding surfaces of the claws, where
the axle goes into the plastic and the locking pin), see picture below.
Open and lock the mechanism continuously to work in the lubricant.
Figure 8.4-1: The picture shows where to lubricate the claw mechanism
