PI CONNECT User Manual

Dimensions: Table case: 115 x 95 x 30 mm
Terminal housing: 114 x 100 x 22.3 mm
6.3 CONNECT II
Supply voltage: 24V DC +/- 20% (via removable plug)
USB (from USB power supply 5V)
Power consumption: 9 watts
Advertisement: Web browser
Status LEDs
Operation/configuration: Web browser
Interfaces: 2 x 10/100/1000BaseTX RJ45 Ethernet jack
2 x antenna socket RP-SMA(f) (2x2 MIMO / 2.4 GHz
IEEE 802.11 b/g/n + 5 GHz IEEE 802.11ac)
Operating temperatur: 0 - 55°C
Housing: Plastic table case
Dimensions: 115x95x30mm
6.4 CONNECT II LTE
Supply voltage: 24V DC +/- 20% (via removable plug)
Power consumption: 19 watts
Advertisement: Web browser
Status LEDs
Operation/configuration: Web browser
Interfaces: 2 x 10/100/1000BaseTX RJ45 Ethernet jack
2 x antenna socket RP-SMA(f) (2x2 MIMO / 2.4 GHz
IEEE 802.11 b/g/n + 5 GHz IEEE 802.11ac)
1 x antenna socket RP-SMA(f) (FDD LTE /TDD LTE /
TDSCDMA / UMTS / GSM)
Operating temperatur: 0 - 55°C
Housing: Plastic table case
Dimensions: 115x95x30mm
Page 75 Handbook CONNECT / CONNECT-II / CONNECT-CONTROL V1.13

PI CONNECT Specifications

General

Model	PI CONNECT
Category	Switch
Port Speed	10/100/1000 Mbps
Management	Unmanaged
Mounting	Desktop
Operating Temperature	0°C to 40°C
Humidity	non-condensing
Ports	8
Power over Ethernet (PoE)	8 x PoE+ (802.3at)
