PI CONNECT User Manual

6 Technical data
6.1 CONNECT
Supply voltage: 24V DC +/- 20% (via removable plug)
USB (out ofPC/power pack, only for table housing)
Power consumption: 2 watts
Advertisement: Web browser
Status LEDs
Operation/configuration: Web browser
Interfaces: 2 x 10/100BaseTX RJ45 Ethernet socket
1 x antenna socket RP-SMA(f) (2.4 GHz IEEE 802.11
b/g/n)
Operating temperatur: 0 - 55°C
Housing: Plastic table caseor
Plastic terminal housing for DIN rail mounting
Dimensions: Table case: 115 x 95 x 30 mm
Terminal housing: 114 x 100 x 22.3 mm
6.2 CONNECT LTE
Supply voltage: 24V DC +/- 20% (via removable plug)
Power consumption: 12 watts
Advertisement: Web browser
Status LEDs
Operation/configuration: Web browser
Interfaces: 2 x 10/100BaseTX RJ45 Ethernet socket
1 x antenna socket RP-SMA(f) (2.4 GHz IEEE 802.11
b/g/n)
1 x antenna socket RP-SMA(f) (FDD LTE /TDD LTE /
TDSCDMA / UMTS / GSM)
Operating temperatur: 0 - 55°C
Housing: Plastic table caseor
Plastic terminal housing for DIN rail mounting
Handbook CONNECT / CONNECT-II / CONNECT-CONTROL V1.13 Page 74

PI CONNECT Specifications

General

Model	PI CONNECT
Category	Switch
Port Speed	10/100/1000 Mbps
Management	Unmanaged
Mounting	Desktop
Operating Temperature	0°C to 40°C
Humidity	non-condensing
Ports	8
Power over Ethernet (PoE)	8 x PoE+ (802.3at)
