6.5 CONNECT CONTROL

Supply voltage: 9-30VDC

Power consumption: 7 watts

Advertisement: Web browser

Status LEDs

Operation/configuration: Web browser

Interfaces: 4 x 10/100BaseTX RJ45 Ethernet socket (3 x

LAN,1xWAN)

2 x antenna socket RP-SMA(f) (2.4 GHz IEEE 802.11

b/g/n)

2 x antenna socket SMA(f) (FDD LTE / TDD LTE / 3G /

2G)

1 x antenna socket SMA(f) (GNSS / GPS)

1 x RS485 port via plug contact

1 x RS232 port via D-Sub 9-pin female

2 x digital input (1 x 0-3V, 1 x 0-30V)

1 x analog input (0-24V)

1 x digital output (open collector, 30V, 250mA)

1 x SPST Digital Relay Output

1 x USB 2.0 female type A

2 x SIM card tray

Operating temperatur: -40 – 75°C

Housing: Metal housing for table or wall mounting

Dimensions: 106x80x46mm

A notice:

The CONNECT-CONTROL hardware corresponds to the RUT955 from

Teltonika Networks.

Handbook CONNECT / CONNECT-II / CONNECT-CONTROL V1.13 Page 76
