PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 113 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Command
Description
Notes
WSL
Set Connection Of Wave
Table To Wave Generator
Must be set before the wave generator can be started.
WSL? Get Connection Of Wave
Table To Wave Generator
WTR Set Wave Generator Table
Rate
Sets the value of the Wave Generator Table Rate
parameter, ID 0x13000109, in volatile memory;
determines the interpolation type for wave table rate
values > 1.
WTR? Get Wave Generator Table
Rate
Gets the value of the Wave Generator Table Rate
parameter (ID 0x13000109) from volatile memory and
the current interpolation type.
#9 Get Wave Generator
Status
Gets the current activation status of the wave
generator, but not the start options (use WGO?
instead)
See "How to Work with the Wave Generator" (p. 99) for more information. For detailed command
descriptions see the GCS commands manual PZ281E. For the identifiers of the items which can be
addressed with the commands see "Axes, Channels, Functional Elements" (p. 22).
Parameter
ID
CCL for
write
access
Item Type
Concerned
Max. No. of
Items
Data
Type
Parameter
Description
0x13000004 3 System 1 INT Max Wave Points
0x13000109
1
System
1
INT
Wave Generator Table Rate
0x1300010a 3 System 1 INT Number of Waves
0x1300010b 1 Logical Axis 3 or 4 FLOAT Wave Offset
0x13000202 1 System 1 INT Wave Multi Start By Trigger
See "Parameters" (p. 185) for more information regarding the controller parameters and their
handling.
