Operation E-727
Supported functions Auto Zero, ID-chip detection
Only accessible via GCS commands: Wave generator, data recorder, macros
Display and indicators LEDs for Power, Servo, Error, Overflow, EtherCAT communication
Linearization 4th order polynomials, DDL (Dynamic Digital Linearization)
Miscellaneous E-727.xxx, E-727.xxxA, E-727.xxxF,
E-727.xxxAF
E-727.xxxP, E-727.xxxAP
Operating temperature range 5 to 40 °C 5 to 40 °C
Overheat protection Deactivation of the voltage output at
72 °C
Deactivation of the voltage output at 72 °C
Alert threshold at 66 °C
Mass 2.4 to 2.6 kg 3.3 kg
Fuse 1 x T3.15 AH, 5 x 20 mm 1 x T4 AH, 5 x 20 mm
Max. power consumption 80 W 84 W
Max. power consumption
without load
24 W 40 W
Operating voltage 24 V DC (external power supply in the
scope of delivery)
24 V DC (external power supply in the scope
of delivery)
Maximum Ratings
The E-727 is designed for the following operating data:
Input on:
Maximum Operating
Voltage
Operating Frequency
Maximum Power
Consumption
M8 panel plug 24 V 80 W
Ambient Conditions and Classifications
The following ambient conditions and classifications must be observed for the E-727:
Area of application For indoor use only
Maximum altitude
2000 m
Relative humidity Highest relative humidity 80% for temperatures up to 31°C
Decreasing linearly to 50% relative humidity at 40°C
Storage temperature 0°C to 70°C
Transport temperature –25°C to +85°C
