Working with Macros
Work with macros comprises the following:
 Recording of macros (p. 123)
 Starting macro execution (p. 125)
 Stopping macro execution (p. 128)
 Setting up a start-up macro (p. 128)
 Deleting of macros (p. 129)
INFORMATION
For working with controller macros, it is recommended to use the Controller macros tab in
PIMikroMove. There you can conveniently record, start and manage controller macros. Details are
found in the PIMikroMove manual.
Recording a macro
INFORMATION
A maximum of 5 nesting levels are possible in macros.
INFORMATION
Basically all GCS commands (p. 181) can be included in a macro. Exceptions:
 RBT for rebooting the E-727
 MAC BEG and MAC END for macro recording
 MAC DEL for deleting a macro
Query commands can be used in macros in combination with the CPY, JRC, MEX and WAC
commands. Otherwise they have no effect, since macros do not send any responses to interfaces.
INFORMATION
To make the use of macros more flexible, you can use local and global variables in macros. See
“Variables” (p. 130) for more information.
