User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 62 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Communication via the USB Interface
Establishing communication via USB
The procedure for PIMikroMove is described in the following. The procedure for other PC software
programs (PITerminal, drivers for use with NI LabVIEW software) is similar.
1. Start PIMikroMove.
The Start up controller window opens with the Connect controller step.
− If the Start up controller window does not automatically open, select the
Connections > New... menu item in the main window.
2. Select E-727 in the field for controller selection.
3. Select the USB tab on the right side of the window.
4. On the USB tab, select the connected E-727.
5. Click Connect to establish communication.
If communication has been successfully established, the Start up controller window switches
to the Start up axes step.
AutoZero Procedure
INFORMATION
During the AutoZero procedure, the axis will move, and the motion can cover the whole travel
range.
