User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 51 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
INFORMATION
The E-727, the stage(s) and any adapter or adapter cable for the stage connection are supplied as
a pre-configured system.
If a connection assignment is given on the labels of the E-727 and/or stage(s) and/or
adapter/adapter cable, observe this assignment when connecting the stage(s).
INFORMATION
When you connect a stage when the controller is powered on, the ID-chip of the stage is not read
by the controller. To read the ID-chip data, the controller must be power-cycled or rebooted using
the RBT command or the corresponding host software functions.
INFORMATION
Pin 2 of the Digital I/O socket can be configured as Reset input, see p. 227 for details. The Reset
input works as follows:
If nothing is connected to pin 2, the signal level is HIGH (internal pull-up with 10 kohm
resistor) which means normal operation of the E-727.
If the signal level on the Reset input becomes LOW, the E-727 is rebooted.
Make sure that the configuration of pin 2 of the Digital I/O socket and the connected signal
comply with your application.
INFORMATION
The E-727 performance can be reduced directly after power on due to thermal instability.
Switch the E-727 on at least one hour before starting work.
If the E-727 is not used, but should remain switched on to ensure the temperature stability:
Make sure that the servo mode is switched off (open-loop operation) and the piezo output
voltage is set to 0 V. To set the piezo output voltage to 0 V, set the axis position to a
corresponding value with the SVA command.
Starting the System in PIMikroMove
Proceed as follows to start the E-727 with the stage(s) in PIMikroMove:
1. Install the following on the PC:
− The PC software and the USB drivers from the product CD
− Updates for PC software
Details see "Installing the PC Software" (p. 43).
2. Make sure that the Power switch of the E-727 is in the OFF position (0).
