Parameter
ID (hexa-
decimal)
Data
Type
Command
Level for
Write
Access
Item Type Parameter
Name
Description
0x02001900 INT 3 Input signal
channel
Lim, Ref Signals
Detectable
Flag that indicates if signals of
limit and reference point
switches are evaluated by the
firmware (does not indicate if
switches are actually present)
0 = no evaluation
1 = switch signals are evaluated
0x02001B00 FLOAT 1 Input Signal
Channel
Maximum
Position Of
Sensor
For future use.
The parameters are only available
if the plausibility check is enabled
with the Check Sensor Position
Plausibility parameter (ID
0x0e001f00)
0x02001C00 FLOAT 1 Input Signal
Channel
Minimum
Position Of
Sensor
0x02001D00 INT 1 Input Signal
Channel
Validate Sensor
Position Range
0x03000n00
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 1 n
Coefficients of the polynomial for
electronics linearization.
n = 1 to 5
For details, see “Digital
Processing”, p. 27.
0x03000
01
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 2 n
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 3 n
0x03000n03
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 4 n
0x03000
04
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 5 n
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 6 n
channel
Correction 7 n
0x03000
07
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 8 n
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 9 n
channel
Correction 10 n
0x03000
0a
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 11 n
0x03000
0b
FLOAT 2 Input signal
channel
Sensor Elec.
Correction 12 n
