PI E-727 User Manual

User Manual
E727T0005, valid for E-727
BRO, 2019-06-28
Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany Page 98 / 240
Phone +49 721 4846-0, Fax +49 721 4846-1019, Email info@pi.ws, www.pi.ws
Parameter
ID
CCL for
write
access
Item Type
Concerned
Max.
No. of
Items
Data
Type
Parameter
Description
0x07001005 1 Logical Axis 3 FLOAT Position Report Scaling,
required if the axis position is to be
output (output type = 2)
0x07001006 1 Logical Axis 3 FLOAT Position Report Offset,
required if the axis position is to be
output (output type = 2)
0x09000000
to
0x09000003
1
Logical Axis
3
FLOAT
Driving Factor of Piezo 1
to
Driving Factor of Piezo 4,
give the output matrix
0x0A000003 1 Output Signal
Channel
4 INT Select Output Type;
1 = output voltage for a piezo actuator
in the stage
2 = position monitor of an axis
5 = control signal for external amplifier
0x0A000004 1 Output Signal
Channel
4 INT Select Output Index;
the selected object can be an axis or an
output signal channel (depends on the
selected output type)
0x0e000b01 3 System 1 INT Number of output channels
0x0e000b04 3 System 1 INT Number of piezo channels
See "Parameters" (p. 185) for more information regarding the controller parameters and their
handling.
