Piper ARROW III Service Manual

1G23
TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABILATOR TRIM CONTROL SYSTEM
Lost motion between Cable tension too low. Adjust in accordance
trim control wheel with Paragraph 5-22.
and trim tab.
Cables not in place on Install cables accord-
pulleys. ing to Paragraphs 5-19.
and 5-21.
Broken pulley. Replace pulley.
Linkage loose or worn. Check linkage and
tighten or replace.
Trim control wheel System not lubricated Lubricate system.
moves with excessive properly.
resistance.
Cable tension too high. Adjust in accordance
with Paragraph 5-22.
Pulleys binding or Replace binding pulleys.
rubbing. Provide clearance between
pulleys and brackets.
Cables not in place on Refer to Paragraphs
pulleys. 5-19 and 5-21.
Trim tab hinge binding. Lubricate hinge. If
necessary, replace.
Cables crossed or Check routing of control
routed incorrectly. cables.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
