Piper ARROW III Service Manual

1G24
TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
STABILATOR TRIM CONTROL SYSTEM (cont.)
Trim tab fails to System incorrectly Check and/or adjust
reach full travel. rigged. rigging per paragraph
5-22.
Trim drum incor- Check and/or adjust
rectly wrapped. rigging per paragraph
5-22.
Trim indicator fails Trim indicator unit Adjust in accordance
to indicate correct not adjusted properly. with Paragraph 5-22.
trim position.
RUDDER CONTROL SYSTEM
Lost motion between Cable tension too low. Adjust cable tension
rudder pedals and per Paragraph 5-29.
rudder.
Linkage loose or worn Check linkage and
tighten or replace.
Broken pulley. Replace pulley.
Bolts attaching rudder Tighten bellcrank bolts.
to bellcrank are loose.
Excessive resistance System not lubricated Lubricate system.
to rudder pedal properly.
movement.
Rudder pedal torque Lubricate torque tube
tube bearing in need bearings.
of lubrication.
Cable tension too high. Adjust cable tension
Per Paragraph 5-29.
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
