Piper ARROW III Service Manual

1H1
TABLE V-III. TROUBLESHOOTING CHART (SURFACE CONTROLS) (cont.)
RUDDER CONTROL SYSTEM (cont.)
Excessive resistance Pulleys binding or Replace binding pulleys
to rudder pedal rubbing. and/or provide clearance
movement. (cont.) between pulleys and
brackets.
Cables not in place on Install cables cor-
pulleys. rectly. Check cable
guards.
Cables crossed or Check routing of control
routed incorrectly. cables.
Rudder pedals not Rudder cables Rig in accordance with
neutral when rudder incorrectly rigged. Paragraph 5-29.
is streamlined.
Incorrect rudder Rudder bellcrank stop Rig in accordance with
travel. incorrectly adjusted. Paragraph 5-29.
Nose wheel contacts Rig in accordance with
stops before rudder. Paragraph 5-29.
RUDDER TRIM CONTROL SYSTEM
Trim control knob System not lubricated Lubricate system.
moves with excessive properly.
resistance.
FLAP CONTROL SYSTEM
Flaps fail to extend Control cable broken Replace or reconnect
or retract. or disconnected. control cable. (Refer
to Paragraph 5-36.)
Trouble Cause Remedy
Issued: 12/15/76
CHEROKEE ARROW III SERVICE MANUAL
SURFACE CONTROLS

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
