Piper ARROW III Service Manual

TABLE VII-IV. MAIN GEAR SERVICE TOLERANCES (cont)
Manufacturers Service Service
Fig. No Part No Nomenclature Dimension Dimension Tol. Remarks
15 402 927 Bolt, side brace link OD .3742 OD .3740
NAS 464 616 assembly + .0000
-.0005
16 452368 Rod end, lowerside brace ID .50+0015 ID .50+0030 0035
(HFX-8TG) link -.0005 -.0005
17 67926-04 Trunnion housing, side ID .7530 ID .7530
67926-05 brace attachment .7550 .7550
18 67026-05 Bushing, Trunnion ID .499 ID .498 004 Install bearing
.500 .502 with wet zinc
chromate on
adjacent sur-
faces of bearing
and casting
19 402 960 Bolt, Trunnion/side OD .4991 OD .4972
(NAS 464 brace attaching + .0000
P8A-44) - .0009
20 67926-04 Trunnion housing, ID .4410 ID .4410
67926-05 torque link attachment .4430 .4440
21 67026-07 (2) Bearing, Trunnion * * ID .314 ID .315 Press Fit Install
.313 using Loctite
601
22 67037-06 Strut Assembly ID .4385 ID .4395 0025
.4370 .4370
23 67026-07 (2) Bearing, strut * * ID .314 ID .315 002 Press Fit
.313 .313
24 67012-00 Torque link(2) ID .312+001 ID .312+002 002
.0000 -.000
25 67012-00 Torque link (2) ID .3760 ID .3745 0025
.3745 .3745
26 31796-00 (2) Bushing, Torque link * * ID .252 ID .253 002 Press Fit
.251 .251
* * Line ream to this dimension after
installation of new part
Revised: 2/13/89
1L14
* CHEROKEE ARROW III SERVICE MANUAL
LANDING GEAR AND BRAKE SYSTEM

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
