Piper ARROW III Service Manual

TABLE XIV-V. BLOWER SYSTEM WIRE COLOR CODES
AIRCRAFT
MOTOR WIRES WIRES
15920 01 E362Q F0018a75FA
Pin General Singer Leece- Aircraft Pin
Nos. Industries Controls Neville Harness Nos.
See Note 2
Ground 2 Brown Brown Black AC26A 2
Low Speed 1 Red Yellow Yellow Black 1
Medium Speed 2 Black Red Red White 2
High Speed 1 Yellow Orange Orange Red 1
NOTE
1. Pin number 1 is at the pointed side of the plug and receptacle.
2. YY15062 ESB-Universal Elect. Co. Motor Wire Colors Same as E362Q
Singer Controls.
Revised: 2/13/89
3B23
CHEROKEE ARROW III SERVICE MANUAL
ACCESSORIES AND UTILITIES

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
