COMPONENT LUBRICANT FREQUENCY
1. RUDDER TUBE BEARING BLOCKS
MIL-L-60326 100 HRS
2. TOE BRAKE CYLINDER ATTACHMENTS MIL-L-7870 100 HRS
3. RUDDER TUBE CONNECTIONS MIL-L-7870 100 HRS
4. BRAKE ROD ENDS MIL-L-7870 100 HRS
Figure 2-17. Lubrication Chart (Control System) (cont.)
Issued: 12/15/76
1C18
*CHEROKEE ARROW III SERVICE MANUAL
HANDLING AND SERVICING
