TABLE III-I. INSPECTION REPORT (cont)
Nature of Inspection
E. CABIN GROUP (cont.)
15.Inspect operation of fuel selector valve.................................................................... O O O
16.Inspect condition of heater controls and ducts.......................................................... O O O
17.Inspect condition and operation of air vents............................................................. O O O
18.Inspect condition of air conditioner ducts................................................................. O O O
19.Remove and clean air conditioner evaporator filter.................................................. O O O
F. FUSELAGE AND EMPENNAGE GROUP
WARNING
Read Note 28 before completing this inspection group.
1. Remove inspection plates and panels (See Note 33)................................................ O O O
2. Inspect baggage door, latch, and hinges for condition operation, and security........ O O O
3. Inspect battery, box, and cables for corrosion, damage, frayed cables, and loose
terminals. (Service every 30 days) Refer to Service Manual or box instructions .... O O O O
4. Inspect all electronic components for security ......................................................... O O O
5. Inspect bulkheads and stringers for damage............................................................. O O O
6. Inspect antenna mounts and electrical wiring for security and corrosion in plugs. . O O O
7. Inspect hydraulic pump motor brushes (Read Note(s) 19 and 28)........................... O O O
8. Check hydraulic pump fluid level (Service as required) .......................................... O O O O
9. Inspect hydraulic pump lines and hoses for damage and leaks ............................... O O O
10.Inspect for obstructions and contamination in inlet of backup landing gear
extender actuator inlet head (if applicable) (Read Note 27)..................................... O O O O
11.Inspect air conditioner system for Freon leaks ........................................................ O O O
12.Check Freon charge in sight gauge of receiver-dehydrator (Refer to Service
Manual, Section XIV................................................................................................ O O O O
13.Inspect air conditioner condenser air scoop rigging................................................. O O O O
14.Inspect fuel lines, hoses, valves, sender units, and gauges for damage and operation . O O O
15.Inspect security of all hoses and lines....................................................................... O O O
16.Inspect vertical fin and rudder surfaces for damage................................................. O O O
17.Inspect rudder hinges, horn, and attachments for damage and operation ................ O O O
18.Inspect vertical fin attachments ............................................................................... O O O
19.Inspect rudder hinge bolts for excess wear (Replace as required)............................ O O O
20.Inspect rudder control stops to ensure stop has not
become loose and jamb nut is tight........................................................................... O O O
21.Inspect stabilator surfaces for damage...................................................................... O O O
22.Inspect stabilator, tab hinges, horn, and attachments for damage and operation...... O O O
23.Inspect stabilator attachments (Refer to latest
revision of Piper Service Bulletin 856)..................................................................... O O O
50 500 1000100
Inspection Time (Hrs)
CHEROKEE ARROW III SERVICE MANUAL
1D11
Interim Revision: 2/21/95 INSPECTION
