TABLE III-I. INSPECTION REPORT (cont)
Nature of Inspection
G. WING GROUP (cont.)
8. Inspect condition of bolts used with hinges (Replace as required)........................... O O O
9. Lubricate per lubrication chart in Service Manual Section II................................... O O O O
10.Inspect forward and aft wing attach fittings for corrosion, general condition and
security. (See latest revision of Piper Service Bulletin 977.).................................... O O O
11.Inspect wing attachment bolts and brackets (Refer to Piper Service
Bulletin(s) 789A and 886) ....................................................................................... O O O
12.Inspect fuel tanks and lines for leaks, water, and contamination ............................. O O O
13.Ensure that fuel tanks are marked for minimum octane rating................................. O O O
14.Inspect the fuel cell vents.......................................................................................... O O O
15.Inspect all control cables, air ducts, electrical leads, hoses, lines, and
attaching parts for security, routing, chafing, deterioration, wear, and
correct installation .(Read Note 23).......................................................................... O O O
16.Install inspection plates and fairings ........................................................................ O O O
H. LANDING GEAR GROUP
WARNING
Read Note 28 before completing this inspection group.
1. Inspect oleo struts for proper extension (Refer to Service Manual, Section VII)
(Check all fluid and air levels as required)............................................................... O O O O
2. Inspect nose gear steering control and travel ........................................................... O O O
3. Inspect wheels for alignment.................................................................................... O O O
4. Lift aircraft on jacks (Refer to Service Manual, Section II)..................................... O O O
5. Inspect tires for cuts, uneven or excessive wear, and slippage................................. O O O
6. Remove wheels; clean, inspect, and repack bearings............................................... O O O
7. Inspect wheels for cracks, corrosion, and broken bolts............................................ O O O
8. Check tire pressure (Refer to Service Manual, Section II)....................................... O O O O
9. Inspect brake linings and discs ................................................................................ O O O O
10.Inspect brake backing plates..................................................................................... O O O
11.Inspect brake and hydraulic lines for leaks, loose fittings, or cracks ....................... O O O
12.Inspect shimmy dampner.......................................................................................... O O O
13.Inspect gear forks for damage .................................................................................. O O O
14.Inspect oleo struts for fluid leaks and scoring .......................................................... O O O
15.Inspect gear struts, attachments, torque links, retraction links, and bolts
for condition and security ........................................................................................ O O O
16.Inspect downlock for operation and adjustment .(Read Note 18) ............................ O O O O
17.Inspect torque link bolts and bushings (Rebush as require) ..................................... O O
18.Inspect drag and side brace link bolts (Replace as required).................................... O
19.Inspect gear doors and attachments ......................................................................... O O O
20.Check warning horn and light for operation............................................................. O O O
50 500 1000100
Inspection Time (Hrs)
CHEROKEE ARROW III SERVICE MANUAL
1D13
Interim Revision: 2/21/95 INSPECTION
