Piper ARROW III Service Manual

TABLE III-I. INSPECTION REPORT (cont)
Nature of Inspection
H. LANDING GEAR GROUP (cont.)
21.Retract gear, check operation and inspect doors for clearance and operation ......... O O O
22.Inspect operation of back-up gear extender system
(If not disabled) (Read Piper Service Bulletin 866.) (Read Note 27)........................... O O O
23.Inspect actuating cylinders for leaks and security ................................................... O O O
24.Inspect all hydraulic lines, hoses, electrical leads, and attaching parts for
security, routing, chafing, deterioration, wear, and correct installation.
(Read latest revision of Piper Service Letter(s) 808 and 810).................................. O O O
25.Inspect position indicator switch and electrical leads for security .......................... O O O
26.Lubricate per lubrication chart in Service Manual, Section II.................................. O O O O
27.Ensure landing gear is down and lockcd; remove airplane from jacks .................... O O O
I. OPERATIONAL INSPECTION
1. Check fuel pump and fuel tank selector.................................................................... O O O O
2. Check fuel quantity, pressure, and flow indications................................................. O O O O
3. Check oil pressure and temperature indications....................................................... O O O O
4. Check alternator performance................................................................................... O O O O
5. Check manifold pressure indications........................................................................ O O O O
6. Check alternate air operation.................................................................................... O O O O
7. Check parking brake operation................................................................................. O O O O
8. Check engine driven vacuum gauge indication........................................................ O O O O
9. Check gyros for noise and roughness....................................................................... O O O O
10.Check cabin heater operation.................................................................................... O O O O
11.Check magneto switches operation........................................................................... O O O O
12.Check each magneto RPM variation; drop etc ......................................................... O O O O
13.Check throttle and mixture operation ....................................................................... O O O O
14.Check propeller operation and smoothness.............................................................. O O O O
15.Check propeller governor operation and reaction..................................................... O O O O
16.Check engine idle operation ..................................................................................... O O O O
17.Check electronic equipment operation ..................................................................... O O O O
18.Check automatic pitch trim, and manual/electric trim operation (Read Note 20).... O O O O
19.Check air conditioner compressor clutch operation ................................................. O O O O
20.Check air conditioner condenser scoop operation.................................................... O O O O
21.Check landing gear system (Read Note 14).............................................................. O O O O
22.After shutdown, check auxiliary electric driven vacuum gauge indication.............. O O O O
J. GENERAL.
1. Aircraft conforms to all FAA specifications............................................................. O O O O
2. All FAA Airworthiness Directives complied with.................................................... O O O O
3. All manufacturers service bulletins and letters complied with................................. O O O O
4. Check for proper night manual................................................................................. O O O O
5. Aircraft papers in proper order ................................................................................. O O O O
50 500 1000100
Inspection Time (HRS)
CHEROKEE ARROW III SERVICE MANUAL
1D14
Issued: FEBRUARY 28, 1989 INSPECTION

Piper ARROW III Specifications

General

Manufacturer	Piper Aircraft
Model	ARROW III
Engine	Lycoming IO-360-C1C6
Horsepower	200 hp
Maximum Takeoff Weight	2, 750 lb (1, 247 kg)
Seating Capacity	4
Propeller	2-blade, constant speed
Length	24 ft 7 in (7.49 m)
