Planmeca ProMax User Manual

Planmeca ProMax 3D Max with ProTouch 21
3D PATIENT EXPOSURE
User’s Manual
Then click the 3D capture button.
Refer to the Planmeca Romexis User’s Manual for details
on Romexis functions.
8.2 Selecting exposure settings
Refer to section 6.6 “Touch screen” on page 12 for
general information on how to make or cancel selections
on the touch screen.
8.2.1 Selecting program
Select the 3D program you wish to use. Refer to section 7
“PROGRAMS” on page 16 for details.
8.2.2 Selecting patient size
Select the patient size according to the build of the
patient.
NOTE The exposure values will automatically change
according to the selected patient size and image
resolution.
XS = Child
S = Small adult
M = Medium-sized adult
L = Large adult
Select patient size:
Fast forward
Forward
(skip next screen)

Planmeca ProMax Specifications

General

Category	Medical Equipment
Type	Cone Beam Computed Tomography (CBCT) System
Software	Planmeca Romexis
Imaging Modes	CBCT
Imaging Modalities	2D Panoramic
X-ray Generator	High Frequency Generator
Focal Spot Size	0.5 mm
X-ray Tube Voltage	60-90 kV
Exposure Time	Varies depending on imaging mode and parameters
Dimensions	Varies significantly depending on model and configuration
Weight	Varies significantly depending on model and configuration
Power Requirements	50/60 Hz
Patient Positioning	seated
