Planmeca ProMax - Physical Dimensions of the X-ray Unit; Minimum Operational Space Requirements

Planmeca ProMax 3D Max with ProTouch 59
TECHNICAL SPECIFICATIONS
User’s Manual
17.3 Dimensions in mm (in.)
17.4 Minimum operational space requirements
NOTE The maximum height can be adjusted to suit offices
with low ceiling.
Width Depth Height
Planmeca ProMax 3D Max 1560 mm
62 in.
1740 mm
69 in.
2490 mm
98 in.
150
(5.9”)
1351 (53.2”)
Ø1010
(39.8”)
788 (31”)
270
(10.6”)
930 (36.6”)
1582 – 2482 (62.3” – 97.7”)
