3D PATIENT EXPOSURE
20 Planmeca ProMax 3D Max with ProTouch
User’s Manual
Attaching head band
If you are using the head band, attach it to the support
bars as shown. The side with the large openings should
be against the patient’s forehead.
Attaching chin cup
Insert the chin cup into the adapter. Insert the adapter into
the holes in the middle of the patient support table.
8.1.2 Preparing Planmeca Romexis
First select the patient.
Attach_headband_25_2.eps
Head band
Support bars
Large openings
Bite1.eps
Chin1.eps
Chin cup
Adapter
